Body Material: Carbide
Brand: Iscar
Coating: TiCN
Corner Radius Re: 1.6 mm
Cutting Direction Hand: Left Hand
Cutting Edge Effective Length Le: 13.85 mm
Cutting Edge Length L: 15.6 mm
Cutting Edge Material: Carbide
Depth Of Cut Maximum Apmx: 12 mm
Grade: IC328
Insert Length Insl: 15.6 mm
Insert Thickness S: 5.6 mm
Insert Width W1: 9.57 mm
Measurement Type: Metric
Shape: 85° Parallelogram
Tool Type: Single sided Inserts
