Fullerton 1" Carbide End Mill 9 Flute FC20 Coating Variable Helix .0900" Radius
Overview
Description
FULLERTON
USA MADE
SOLID CARBIDE END MILL
Features
The 3600 Force is a high performance end mill available with 5, 7, or 9-flutes
It produces excellent surface finishes and chip control and its optimized geometry allows for high feed rates in stainless steels, super alloys, and titanium
The 3600 Force is stocked with FC-20 coating
Product Specifications
Cutting Diameter (Decimal Inch)
1"
Cutting Diameter (mm)
25.40mm
Cutting Diameter (Inch)
1"
Cutting Flute Length (Decimal Inch)
1.2500"
Cutting Flute Length (mm)
31.75mm
Cutting Flute Length (Inch)
1-1/4"
Shank Diameter (Decimal Inch)
1"
Shank Diameter (mm)
25.40mm
Shank Diameter (Inch)
1"
Overall Length (Decimal Inch)
4.0000"
Overall Length (mm)
101.60mm
Overall Length (Inch)
4"
Coating/Finish
FC20
Metric/Inch
Inch
Number of Flutes
9
Helix Angle (Degrees)
Variable
Flute Spiral Direction
Right Hand
Direction of Cut
Right Hand
Point End Type
Corner Radius
End Type Character Designation
R
Radius (Decimal Inch)
0.0900"
Radius (mm)
2.29mm
End Type
Single End
Coolant Through
Non Coolant Through
Weldon Flat
No
Length
Standard
Length Designator
SD
