Dormer 3/4-16 HSS-E-PM Spiral 4 Flute Tap TiAlN Yellow Ring 5.51 Long

DORMER

HSS-E-PM SEMI-BOTTOMING SPIRAL FLUTE TAP

Thread Diameter Size (TDZ): 1″
Standard: | DIN | ANSI |
Threads per Inch (TPI): 12
Tool Type: Machine Tap
Thread Standard: | UNF |
Chamfer: 2P-3P
Overall Length (OAL): 5.512″
Coating: TiAlN
Thread Cutting Part Length (THL): 1.063″
Flute Type: Spiral
Connection Diameter Machine Side (DCONMS): 0.8″
Style: Semi-Bottoming
Flute Count (NOF): 4
Cutting Direction (HAND): Right Hand
Flute Helix Angle (FHA): 40 Degrees
Coolant Supply Property (CSP): External
Applicable Material: | Steel |
Length Group: 2xD
Cutting Edge Material: HSSE-PM
Square Size: 0.597″
Thread Tolerance Class (TCTR): | H6 |
Measurement Type: Fractional
Special Feature: Yellow Shark
Series/List #: E908
