| Swing | 21" | 533.4 mm |
| Machining Length | 23" | 584.2 mm |
| Max. Turning Diameter | 18" | 457.2 mm |
| X-Axis | 12.5" | 317.5 mm |
| Y-Axis | ± 2" | ± 2" |
| Z-Axis | 23" | 584.2 mm |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 2" | 50.8 mm |
| Spindle Nose | A2-6 | A2-6 |
| Power | 30 hp | 22.4 kW |
| Max RPM | 4,500 RPM | 4,500 RPM |
| Tailstock | No | No |
| Live Tooling | Yes | Yes |
| Live Milling Max RPM | 4000 rpm | 4,000 RPM |
| Sub Spindle | Yes | Yes |
| Sub Spindle Chuck | 8.3 in | |
| Dimensions | 171" x 90" x 98" | 171" x 90" x 98" |
| Weight | 12,200 Lbs | 12,200 Lbs |
HAAS CNC Control
Automatic Tool Presetter
Mist Collector
Live Tooling
Rigid Tapping
Spindle Orientation
Chip Conveyor
Auxiliary Coolant Filter
