USED 2000 AFCO 504872-48"

Specifications:
Max Coil Weight: 50,000 Lbs
Max Coil Width: 48”
Min Coil Width: 10”
Max Coil OD: 72”
ID Expansion Range: 22” To 26”
Max Stock Thickness At Full Width (48”): 0.125”
Min Stock Thickness At 48”: 0.020”
Max Thickness At 24”: 0.177”
Max Coil Dia: 72”
Yield Range: 25,000 PSI To 60,000 PSI
Feeding Length: 2” To 36”
Line Speed: 100 FPM
SPM: 60
Feeding Angle: Adjustable
Passline Height: ±5”
Feeding Direction: Right To Left
Material Capability:
Cold Rolled Steel
HD Galvanized
Electro Galvanized
Control:
Drive System: Unico
PLC: Allen Bradley
Operator Interface: IBM, Wonderware
Includes:
Servo Driven Reel
Entry Pinch Roll Crop Shear
Six High Straightener (Servo Driven)
AC Servo Feeder With Powered Programmable Passline Height Adjustment
Powered And Programmable Stock Guides
AC Servo Exit Feed With Scrap Chopper
All features certainly not on a normal 48” feed line.
