Overview
Type:
Rolling Mills
Manufacturer:
WATERBURY FARREL
Year:
1967
Stock #:
VX-17531
Description

200" Max Gauge (5 mm)
47" O.D. (1190 mm)
16" I.D. (406 mm)
5700 Lbs Coil Weight (2610 Kgs)
20" I.D. (508 mm)
850 RPM
Combination Pinion
Gearbox: 12:1 Ratio

Specifications

Material: Steel
Configuration: 4 High, Non Reversing
Mill width: 24" (610 mm)
Starting coil: 19" Wide (482 mm)
Finished coil: 0.035" Max Gauge (0.88 mm)
Line speed: 300 FPM (91 MPM)
Direction of travel: Right To Left
Housing: Closed Top, Cast
Work rolls: 11" Diameter x 24" Face (279 mm Diameter x 610 mm Face)
Work roll chocks: Roller Bearing
Backup rolls: 25" Diameter x 24" Face Backup Roll (635 mm x 610 mm)
Backup chocks: Roller Bearing
Screwdown: Electro Mechanical
Payoff coil car: Blocker Roll Saddle Type
Payoff reel: Expanding Mandrel Type
Payoff motor: 100 HP (75 Kw)
Mill stand: 500 HP
Exit reel style: Expanding Mandrel
Exit reel mandrel: 20" Diameter (508 mm)
Exit reel motor: 150 HP (110 Kw)
Exit coil car: Lift & Transfer Type
