Professionally repaired by knowledgeable and experienced service engineers.
Setup and test bent for accuracy, ready to demo.
| Tonnage | 88 T | 79.832 t |
| Type | HYD | HYD |
| Overall Length | 100" | 2.5 m |
| Between Housings | 83" | 2.1 m |
| Stroke | 7.87" | 199.9 mm |
| # Axis | 8 | 8 |
| Control | CNC | CNC |
| Dimensions | 120”L x 60”W x 96”H | 120”L x 60”W x 96”H |
| Weight | 12,680 Lbs | 12,680 Lbs |
Tonnage: 88 Tons
Overall Bending Length: 100”
Distance Between Housings: 83”
Open Height: 18.5”
Ram Stroke: 7.8”
Throat: 16.5”
Closed Height: 10.67”
Approach Speed: 240 IPM
Forming Speed: 223 IPM
Return Speed: 188 IPM
Back Gauge Travel: 27.6”
Main Motor: 25 Hp
Dimensions: 120”L x 60”W x 9’6”H
Weight: 28,700 Lbs
Amada Operateur OP2 CNC Control
Remote Foot Pedal
6 Axis Back Gauge
Remote Handwheel
