| Guide | Spur | Spur |
| Maximum External Gear Diameter | 18" | 457.2 mm |
| Maximum Internal Gear Diameter | 18" | 457.2 mm |
| Diametral Pitch | 3 | 3 |
| Riser | 5" | 127 mm |
| Stroke | 5" | 127 mm |
| Dimensions | 5'3" x 4' x 6'5" | 5'3" x 4' x 6'5" |
| Weight | 6800 Lbs | 6800 Lbs |
Specifications:
Stroke: 5"
Maximum External & Internal Pitch Diameter: 18"
Maximum Face Width, External: 5"
Maximum Face Width, Internal: 5"
Maximum Diametral Pitch, Spur: 3/4
Dimensions:
Maximum Overall Length of Machine: 5'3"
Maximum Overall Width of Machine: 4'
Maximum Overall Height of Machine (w/out raising blocks): 6'5"
Approx. Weight: 6800 lbs.
Spur Guide
5" Riser
Coolant Pump
(1) Set-Up of Change Gears
