| Maximum Diameter Gear | 20" | 508 mm |
| Maximum Face Width | 3" | 76.2 mm |
| Maximum Cone Distance | 10" | 254 mm |
| Control Manufacturer | Conventional | Conventional |
| Dimensions | 118" x 86.5" x 70" | 118" x 86.5" x 70" |
| Weight | 18,820# | 18,820# |
Specifications:
Minimum Outside Cone Distance: 2.75"
Maximum Cone Distance: 10"
Maximum Gear Pitch Dia.: 20"
Cutter Diameters Utilized: 9 - 18"
Root Angle: 55 - 80 Deg.
Face Width: 3"
Number of Teeth: 20 -75
Diameter of Taper Hole at Large End: 3-27/64"
Taper Per Foot: .50"
Depth of Taper: .625"
Cutter Speeds: 15.6 to 87.7 RPM
Feeds (seconds/tooth): 5 to 34.3
Main Motor: 10hp, 1800 rpm
Hydraulic Motor: 7.5hp, 1800 rpm
Approximate Floor Space: 118" x 86.5" Needed
Overall Height: 70"
Approximate Net Weight: 18,820 lbs
Shipping Weight Boxed for Export: 20,500 lbs
Hydraulic Work Clamping
Chip Conveyor
Cutter Clamping Bolt
Index Plate
Change Gears
Hydraulic System
Coolant System
