USED 1997 CLEAVER BROOKS CB700-30

Cleaver-Brooks 100 HP Low-Pressure Hot Water Boiler

Overview

Used Cleaver-Brooks CB700-30 hot water boiler (1997) for sale. This low-pressure boiler is designed to provide efficient and reliable hot water generation for various industrial applications.

Design and Performance
1. 100 HP output
2. 30 PSI design pressure
3. 3,350,000 BTU/hr heating capacity
4. Natural Gas fuel
5. Water capacity: approximately 390 gallons
6. Serial Number: L-98001

Electrical Requirements
1. Main Power: 480V, 3-phase, 60Hz (5.5A)
2. Control Circuit: 120V, 1-phase, 60Hz (7A)
3. Blower Motor: 2 HP

Mechanical Features
1. Boiler weight: approximately 12,000 pounds (boiler only)
2. Dimensions: 18 ft 1 in (L) x 7 ft 9 in (W) x 8 ft 6 in (H)
3. Boiler with burner and pumps: approximately 15,000 pounds

Safety Features
1. Maximum Rating of Circuit Protection: 18.7A
2. Minimum Circuit Ampacity: 6.4A

Ideal Applications
1. Industrial processing (food, textile, pharmaceutical)
2. Commercial heating (hospitals, hotels, office buildings)
3. Chemical processing
4. Paper mills

Benefits
1. Low-pressure steam generation
2. Efficient fuel consumption
3. Reliable operation
4. Easy maintenance
5. Cost-effective solution

Additional Information
1. Manufacturer: Cleaver-Brooks
2. Model: CB700-30
3. Year Built: 1997
4. Boiler Type: Hot Water Boiler
