Work chamber (W x D x H): 30 x 18 x 22” (76 x 46 x 56 cm).
Shelf supports restrict overall clear width to 28” (72 cm)
Capacity: 6.9 cubic foot (195 liters).
Overall external dimensions (W x D x H): 36 x 26 x 36” (92 x 65 x 92 cm).
Heater with fast response open coils:
Power Capacity:
2.4 kW available on 120/1/50-60 power
2.4 kW available on 240/1/50-60 power
Operating range: 35°C to 204°C (95°F to 400°F).
Minimum temperature achieved with 20°C air at fresh air inlet and damper fully open.
Temperature displays in degrees Centigrade on all standard equipment. Fahrenheit display available on special request.
Recirculating motor: 1/25 HP; airflow capacity: 120 CFM (56.6 LPS).
