NEW 2025 HENDRICK MANUFACTURING HHD-V

The 2025 Hendrick Manufacturing HHD-V Series 5-Axis CNC Router is a powerful, heavy-duty machining center designed for complex, multi-surface milling applications across demanding industries such as aerospace, marine, mold-making, architectural fabrication, and advanced composites. Built for high-precision, large-format machining, the HHD-V Series offers full simultaneous 5-axis motion, allowing for the creation of intricate geometries and compound curves in a single setup.
Featuring a rigid gantry design, high-speed servo motors, and a robust 5-axis spindle head, the HHD-V delivers superior cutting performance and part accuracy. Its advanced CNC control platform provides dynamic toolpath execution and supports leading 5-axis CAM software. This machine is ideal for high-volume production and custom one-off jobs requiring the highest standards of dimensional accuracy and surface finish.

Technical Specifications (Typical for the HHD-V Series – confirm with actual machine build):

Model: HHD-V Series

Year: 2025

Axis Configuration: Full 5-axis (X, Y, Z + A [tilt], C [rotation])

Table Size: Commonly 5' x 10' or 6' x 12' (custom sizes available)

Z-Axis Travel: 24" or greater for deep-profile cutting

A-Axis (Tilt): ±120°

C-Axis (Rotation): ±360° continuous

Spindle: 15–20 HP 5-axis high-frequency spindle (e.g., HSD, Colombo)

Spindle Speed: Up to 24,000 RPM

Tool Changer: Automatic tool changer (ATC) with 8–20 tools (carousel or rack type)
Drive System:

X & Y Axes: Helical rack and pinion

Z Axis: Precision ball screw

Guideways: Heavy-duty linear rails

Vacuum Table: Zoned vacuum hold-down system with industrial vacuum pump

Control System: Advanced 5-axis CNC controller (e.g., Siemens, Fanuc, Fagor) with touchscreen interface

Software Compatibility: Supports 5-axis G-code from leading CAD/CAM systems (Mastercam, HyperMill, Fusion 360, RhinoCAM, etc.)

Accuracy: ±0.002"

Repeatability: ±0.001"

Electrical Requirements: 208V–480V, 3-phase, 50/60 Hz (depending on configuration)

Footprint: Approx. 12' x 18' or larger depending on table and gantry size

This is a basic description and is provided for informational purposes only. All specifications, features, and details should be independently verified by the buyer.
