NEW 2025 HENDRICK MANUFACTURING HSR-R

Upgrade your production line with the powerful HSR Series 3-axis CNC router. This incredible machine can handle even the most demanding production requirements thanks to its world-class mechanical and electronic components. This 3-axis CNC router delivers high-speed positioning and cutting without sacrificing the finish quality. It’s compact stationary table moving gantry design will free up floor space in your production area. Each machine comes with a multi-station rotary tool changer or a linear rack tool holder. These powerful 3-axis CNC machines for sale are ideal for all your manufacturing needs. Versatility, compact design, and 24/7 uptime – get all this and more with the HSR Series.

Technical Specifications (Typical for HSR-R Series – please verify exact machine configuration):

Model: HSR-R Series

Year: 2025

Axis Configuration: 3-axis (X, Y, Z)

Table Size: Approx. 5' x 10' (60" x 120") working area

Z-Axis Travel: Up to 8–12 inches (depending on configuration)

Spindle: 10–15 HP HSD or Perske spindle (variable-speed, air- or liquid-cooled)

Spindle Speed: Up to 24,000 RPM

Tool Changer: Optional automatic tool changer (ATC) with 6–12 tool positions

Drive System: Precision ball screw or helical rack & pinion (on selected axes)

Guideways: Linear motion guide rails for high accuracy and reduced wear

Vacuum Table: Integrated zoned vacuum hold-down system

Control System: PC-based or standalone CNC controller (e.g., Fagor, Fanuc, or proprietary)

Software Compatibility: Supports G-code; compatible with most major CAD/CAM platforms (e.g., Vectric, Mastercam, Fusion 360)

Repeatability/Accuracy: ±0.001–0.003 inches (depending on configuration)

Electrical Requirements: 208–230V / 3-phase / 50–60 Hz (varies by model)

Footprint: Approx. 10 ft x 14 ft (varies depending on table and configuration)

This is a basic description and is provided for informational purposes only. All specifications, features, and details should be independently verified by the buyer.

* Model: HSR-R Series
