NEW 2025 HENDRICK MANUFACTURING HLD-L

The 2025 Hendrick Manufacturing HLD-L Series CNC Router is a precision 3-axis machining center engineered for high-speed, high-accuracy routing of wood, plastics, aluminum, and composite materials. Designed with heavy-duty construction and advanced motion control, the HLD-L Series offers exceptional rigidity, repeatability, and flexibility—ideal for industries such as cabinetry, aerospace, signage, and general manufacturing.
This model is equipped with a powerful high-speed spindle, advanced servo-driven axes, and a vacuum hold-down table for secure and efficient material processing. The user-friendly interface and open software compatibility make the HLD-L a reliable choice for both high-volume production and custom work.

Technical Specifications (Typical for the HLD-L Series – confirm exact configuration):

Model: HLD-L Series

Year: 2025

Axis Configuration: 3-axis (X, Y, Z)

Table Size: 5' x 10' (60" x 120") standard; other sizes may be available

Z-Axis Travel: 8"–12" (depending on spindle and gantry configuration)

Spindle: 12–15 HP HSD or similar high-frequency spindle

Spindle Speed: Up to 24,000 RPM

Tool Changer: Optional automatic tool changer (ATC) with 8–12 tool positions
Drive System:

X & Y Axes: Helical rack & pinion

Z Axis: Precision ball screw

Guideways: Heavy-duty linear rails for smooth, high-speed motion

Vacuum Table: Zoned vacuum hold-down system with multiple zones

Control System: PC-based CNC control with touchscreen HMI; supports G-code

Software Compatibility: Compatible with most CAD/CAM platforms including VCarve, Aspire, Fusion 360, and Mastercam

Positioning Accuracy: ±0.002" – ±0.003"

Repeatability: ±0.001"

Electrical Requirements: 208–230V, 3-phase, 50/60 Hz

Overall Footprint: Approx. 10 ft x 14 ft (varies with table size and accessories)

This is a basic description and is provided for informational purposes only. All specifications, features, and details should be independently verified by the buyer.
