NEW 2025 HENDRICK MANUFACTURING HSR-V

The 2025 Hendrick Manufacturing HSR-V Series 5-Axis CNC Router is a high-precision, heavy-duty machining center engineered for complex, multi-dimensional cutting tasks across a wide range of materials, including wood, composites, plastics, and non-ferrous metals. With full 5-axis motion control, this router is ideal for advanced manufacturing applications in aerospace, marine, automotive, mold-making, and architectural components.
The HSR-V Series features a rigid steel frame, a high-torque 5-axis spindle, and a precision servo-driven motion system that ensures smooth, accurate operation even on intricate geometries. Its advanced control interface supports simultaneous multi-axis machining, offering full flexibility for producing contoured, angled, or undercut parts in a single setup. Combined with a vacuum hold-down table and automated tool changing, this machine is built for high throughput and demanding precision.

Technical Specifications (Typical for HSR-V Series – verify specific machine configuration):

Model: HSR-V Series

Year: 2025

Axis Configuration: 5-axis (X, Y, Z, A, C)

Table Size: Approx. 5' x 10' (custom sizes available)

Z-Axis Travel: 24"+ (extended travel for deep or tall components)

A-Axis (Tilt): ±120°

C-Axis (Rotation): ±360° continuous

Spindle: 15–20 HP HSD or equivalent 5-axis spindle

Spindle Speed: Up to 24,000 RPM

Tool Changer: Automatic tool changer (ATC) with 8–16 position carousel or rack
Drive System:

X/Y Axes: Helical rack & pinion

Z Axis: Precision ball screw

Control System: Industrial CNC controller with multi-axis kinematics support (e.g., Siemens, Fagor, Fanuc, or proprietary)

Software Compatibility: Supports 5-axis post-processing from CAD/CAM platforms like Mastercam, Fusion 360, RhinoCAM, and HyperMill

Positioning Accuracy: ±0.002"

Repeatability: ±0.001"

Vacuum Table: Multi-zone vacuum hold-down with high-flow pump system

Electrical Requirements: 208–230V or 460V, 3-phase, 50/60 Hz (based on configuration)

Overall Footprint: Approx. 12 ft x 16 ft (varies by table and gantry size)

This is a basic description and is provided for informational purposes only. All specifications, features, and details should be independently verified by the buyer.
