Used Voltage Transformer (B)

The information provided is a general overview and is intended for informational purposes only. Specifications and features may vary depending on the model year, customizations, or specific configurations.

Key Features of Jefferson Electric Voltage Transformers

Power Ratings: Available from 50 VA to 5,000 VA, catering to a wide range of applications.

Voltage Configurations: Support primary voltages up to 4,160V and secondary voltages typically ranging from 120V to 480V, accommodating various system requirements.

Construction: Utilize high-grade silicon steel cores and machine-wound copper coils for durability and efficient performance.

Frequency: Designed for 50/60 Hz operation, ensuring compatibility with standard electrical systems.

Temperature Rise: Units are rated for temperature rises of 55°C to 115°C, depending on the model, to handle varying load conditions

Standards Compliance: Built in accordance with NEMA, ANSI, and UL standards, ensuring safety and reliability.

Optional Features: Some models offer features like finger-safe terminals, parallel connections, and secondary fuse clips for added convenience and safety.
