Equipped with
Independently Suspended Bottom Platen
High Quality, Precision Built Steel Construction
Independent Dual Temperature Controls
Separate Temperature Controls for Each Heated Platen
Fast, Efficient, Long Life Heaters
Compact Footprint
20 ton Hydraulic pump and jack
About section
Vulcanization is a necessary step to prepare the uncured silicone mold for spin-casting production. Under controlled heat and pressure the silicone slowly cures to a heat resistant, flexible, permanent mold. TEKCAST’s 3-Post design ensures that the heating platens stay parallel during vulcanization and produce parallel, accurate molds. Additionally, in the unlikely event a unit requires calibration, it is a simple and easy process. Our Vulcanizers are jam-free as the bottom platen is independently suspended on the hydraulic jack ram.
For the home business hobbyist / jeweler / craftsman, to produce fishing lures, jig, sinkers and Jewelry related items -Belt Buckles. low-melting metal alloys (zinc, tin, bismuth, eutectic alloys and lead). We have much more available equipment tested and ready to work. Including Charles Hones pewter melting furnaces, Casting Machines, Mold frames 9",10",12". Available for additional cost from Gold International Machinery-Rhode Island's one stop shop for all machine needs.
Voltage: 230V 50/60HZ
Design: Unique 3-Post Design
Platen size: 14"
Overall Size: 18" x 18" x 38" high
Approximate weight: 700 Lbs
