USED 1977 GLEASON 608
Overview
Specs
Specifications:
Minimum Outside Cone Distance: 2.75"
Maximum Cone Distance: 10"
Maximum Gear Pitch Dia.: 20"
Cutter Diameters Utilized: 9 - 18"
Root Angle: 55 - 80 Deg.
Face Width: 3"
Number of Teeth: 20 -75
Diameter of Taper Hole at Large End: 3-27/64"
Taper Per Foot: .50"
Depth of Taper: .625"
Cutter Speeds: 15.6 to 87.7 RPM
Feeds (seconds/tooth): 5 to 34.3
Main Motor: 10hp, 1800 rpm
Hydraulic Motor: 7.5hp, 1800 rpm
Approximate Floor Space: 118" x 86.5" Needed
Overall Height: 70"
Approximate Net Weight: 18,820 lbs
Shipping Weight Boxed for Export: 20,500 lbs
F.O.B. TRUCK, LOCATION
Equipped With
Index Plate
Geneva Cam
Cutter Body
Hydraulic Work Clamping
Coolant Pump & Tank
Chip Conveyor
Additional Cutter Bodies, Index Plates & Geneva Cams Available
