| Guide | Spur | Spur |
| Maximum External Gear Diameter | 8" | 203.2 mm |
| Maximum Internal Gear Diameter | 8" | 203.2 mm |
| Diametral Pitch | 57 | 57 |
| Riser | 2" | 50.8 mm |
| Stroke | 0" | 0 mm |
| Cutter Spindle Diameter | 0" | 0 mm |
| Dimensions | 66" x 44" x 81" | 66" x 44" x 81" |
| Weight | 6,750# | 6,750# |
Specifications:
Max. Pitch Diameter: 8" (Internal & External)
Max. Diametral Pitch: 5/7 Spur; 6 Helical
Max. Face Width: 1 1/2" Internal; 2" External
Max. Stroke: 2-1/4"
Max. Helix Angle W/Standard Guides: 38 Degrees 41'
Diameter of the Cutter Spindle 3-3/8"
Speeds Six from 200 to 600 strokes per minute
Overall Dimensions: 66"L x 44"W x 81"H
Net Weight W/Motors: 6,750#
FOR TRUCK WARREN MICHIGAN
2" Riser
Spur Guide
2-Speed Stroke Selection
Operating Extension for Internals
Rapid Approach
Lube System
Hydraulics
Coolant System
Motor and Controls
Operating Light
Operators Manual
