New GoldPro® FIOA Mechanical Ice Diamond Cutting Lathe

New GoldPro® FIOA Mechanical Ice Diamond Cutting Lathe

Safety note

Buying from non-Pro sellers
Non-Pro sellers can be individuals or smaller businesses. Equipt does not verify every seller or inspect every item. Confirm who you're dealing with, ask for recent photos or video, and only pay through secure, traceable methods.

This seller is not an Equipt Pro dealer. Equipt does not inspect items, handle payment or guarantee transactions. Verify the seller and equipment before sending funds.

How to stay safe with non-Pro sellers

Equipt connects buyers and sellers of industrial equipment. We don't own the machines, inspect them in person or process payment for you, so it's important to do your own checks—especially with sellers who are not using Equipt Pro.

Before you commit:
  • Confirm the seller's business name, address and contact details
  • Ask for recent photos or video of the equipment running, including serial plates
  • Request invoices, maintenance records or proof of ownership when appropriate
  • Compare pricing against similar listings to spot offers that look too good to be true
When paying:
  • Use secure, traceable payment methods (no cash or untraceable transfers)
  • Be cautious if a seller pressures you to move very fast or change payment details last minute
  • If anything feels off, pause the transaction and contact Equipt support before proceeding

Taking a few extra steps up front greatly reduces the risk of scams and helps keep the Equipt marketplace safe for everyone.

Overview
Type:
Diamond Tool Lathes
Stock #:
776255
Description

THE LATHE IS COMPLETE WITH:
ELECTRONIC AUTOMATION.
DOUBLE CHAMBER CYLINDER Ø320x700 mm.
ADJUSTABLE SPINDLE SPEED WITH POTENTIOMETER FROM 0 TO 600 rpm.
SPEED OF SPINDLE: 0 ÷ 600 RPM
MANDREL SPEED CONTROLLED BY PEDAL KEYBOARD: RPM 0 ÷ 150
BLOCKING DEVICE IN CASE OF BREAKING CHAIN.
ADVANCING OF THE HEAD BY MEANS OF POTENTIOMETER
WORKING HEIGHT: 200 mm.
DISTANCE BETWEEN THE TAILSTOCKS: 1000 mm.
CYLINDER DIAMETER: 320 mm.
MOTOR POWER: 4/6 + 1 HP
OVERALL DIMENSIONS: 2250x1050x1350h mm. Approx.
WEIGHT: 1400 ÷ 1500 KG. Approx.

Specifications

On bed center height: 200mm
Distance between centers: 1000mm
Allowed diameter on slide: 320mm
Bed width: 260mm
Spindle hole: 52mm
Spindle nose: 6
Spindle speed: 36/1600
Tailstock sleeve diameter: 100mm
Motor: 5.5 HP
Machine weight: 1400 Kg
