Crucible Size: 50 KG
Maximum Casting Capacity: 4" (100mm)
Output Capacity: 50 KG PER HOUR
Voltage: 208 / 220 / 240 50-60 CY.
Kw Power: 40
Amps: 110
Maximum Operating Temperature: 1260º C (2300º F)
Furnace Box: Heavy duty HR steel construction with removable top.
Heating Element: The heating element is constructed of silicone carbide. The element is designed to provide trouble free life. The element has a unique design the easiest and shortest way to replace. (normal replacement time is 15 min. with Furnace HOT)
Insulation: The furnace chamber contains multiple courses of high quality refractory and thermal efficiency.
Atmosphere Control: Internally the Furnace operates under atmosphere inert gas. This will minimize oxidation of graphite crucible and die.
Heat Zone: Multi Zone heating system for better heat curve accuracy.
Temperature: Microprocessor temperature control with time proportion and cycle rate calibrated for Type K thermocouple 0 to 2,300º F for close line control. (includes HI-Limit safety)
Panel Board: Will be equipped with all necessary switches and controls for efficient operation. The panel will be wired and instruments will be tested before leaving our plant.
Cooling System: Cooling system specially designed pressure less cooling chamber including prevision flow meter control to monitor accurately the cooling and water temperature gauges with micro-processor control to activate the alarm system. Water pressure control is also interfaced with the alarm system.
Withdrawal System: The withdrawal mechanism is designed with mechanical and hydraulic interface. The motor drive is controlled electronically with processor pulse.
Crucible: Manufacture from high purity. Graphite is machined to precision tolerance.
Dies: Casting Dies are precision manufactured from high density graphite.
Overall Dimensions: 60" L x 40" W x 48" H
Estimated Weight: 2800 lbs. (1270 kg)
