Overview
Type:
Solid Dose Bottling Complete Packaging Lines
Manufacturer:
SCHUBERT PACKAGING
Model:
TLM
Year:
2017
Stock #:
757331
Description

Manufacturer: Schubert Packaging

Machine type: TLM

Year of manufacture: 2017

IBN: January 2, 2018

Condition: Functional, very well maintained

Availability: immediately


1. General
Identification feature
Manufacturer Schubert Packaging Services GmbH
Machine type TLM

Inventory no. 56149
Technical feature Value Unit
Secondary packaging machine with robots 8 units
Product transport via transmodule

Package production 6 units
Filling and sealing packages 7 units
Machine speed 30–40 1/min
Ultrasonic sealing Sealing packages 1 unit
Mark and verify unit for serialization 1 unit
Operating mode Cyclical, robot per station
Operating side Right in the direction of goods outflow
Drive side Left in the direction of goods outflow
Number of uses 3 per transmodule/cycle
Running performance (max. machine cycle) 30–40 packages/min
2. Energy connections
Technical feature Value Unit
Electrical connection power 70 kW
Compressed air, pressure 6 bar
Compressed air, max. volume flow 0.5 m³/h
Cold water 1/2 inch

Technical data
Secondary packaging

Technical data_56149_00 Status: 02.11.2017 / DP Page 2 of 2
3. Electrical
Technical feature Value Unit

Electrical connection

Voltage 400 / 230 V
Frequency 50 Hz
Current 75 A
Phases 3

Total power 52 kW
Cable cross-section 50 mm2
4. Control / Protection classes

Designation
Control Schubert
Control voltage 24 V
Visualization / Control panel Schubert BFTerminal
IP protection class IP 23 or higher

Production process: secondary packaging

Assembly and filling of plastic trays with sealed edge bags.

                  This includes: feeding, counting, and weighing of sealed edge bags,

                  feeding and sealing of trays and cardboard blanks using ultrasonic sealing,

                  filling the finished trays with the sealed edge bags and a patient information leaflet,

placing a closure lid in the bottom tray, sealing and labeling the finished tray.



The machine was decommissioned due to a product discontinuation.

Complete operating instructions are available.

Viewing is possible by arrangement.
