3-AXIS ADJUSTMENT
4" TOTAL SIDE-TO-SIDE VIA HAND SCREW
3-1/2" TOTAL UP & DOWN VIA HAND SCREW
360 DEGREES ROTATIONAL ADJUSTMENT
PROFILE, MAX.: 4" x 6" (EST)
LARGEST TOOL PROFILE WITH CURRENT:
INSERT HOLDER: 2-3/4" X 3-3/4"
SIZE OF CURRENT TOOL HOLDER: 5" x 7-1/2"
DIAMETER OF ROTARY INSERT: 9-3/4"
PASSLINE HEIGHT, WITHOUT MOUNTING PLATE: 7" TO 10-1/2"
PASSLINE HEIGHT, WITH MOUNTING PLATE: 8-3/4" TO 12-1/4"
