| Dimensions | 60'x 73" | 60'x 73" |
| Weight | 5,300# | 5,300# |
Specifications:
Diameter of Gear: 20" Max.
Offset Of Gear Spdl. Above Or Below Center Of Pinion Spdl.: 3-1/2" Max.
Dis. From Center Of Gear Spdl. To Nose Of Pinion Spdl.: 12" Max, 6" Min.
Dis. From Center Of Pinion Spdl. To Nose Of Gear Spdl.: 7-3/4" Max.,
4-1/8" Min.
Diameter Of Gear: 20" Max.
Speed Of Drive Spdl: 1200 RPM
Motor Required: 5 HP
Floor Space: 60" x 73"
Net Weight: 5300 lbs
Manual/Auto Cycle
Hydraulic Clamping
Bijur Lube
