| Maximum Pinion Outside Diameter | 6" | 152.4 mm |
| Dimensions | 75.5" x 69" x 90" | 75.5" x 69" x 90" |
| Weight | 8,400# | 8,400# |
SPECIFICATIONS:
Maximum Gear Diameter: 10.50"
Maximum Pinion Diameter: 6.00"
Pinion Spindle Diameter Of Taper Hole At Large End: 3.91"
Pinion Spindle Depth Of Taper: 3.00"
Gear Spindle Diameter Of Hole Thru Spindle: 2.50"
Gear Spindle Taper Per Foot: 0.50"
Gear Spindle Diameter Of Hole Thru Spindle: 2.19"
Floor Space (W x L): 75.5" x 69"
Height of Machine: 90"
Net Weight (Approximate): 8,400 lbs
Lap System
Hydraulic Chucking
Automatic Backlash Eliminator
Power Traverse
Guide
Hydraulic System
Automatic Splash Doors
