| Tonnage | 300 T | 272.156 t |
| Stroke | 6" | 152.4 mm |
| Shut Height | 24" | 609.6 mm |
| SPM | 80 strokes/min. | 80 strokes/min. |
| Vari Speed (Yes/No) | Yes | Yes |
| Bed W | 72" | 1,828.8 mm |
| Bed L | 36" | 914.4 mm |
| Air Clutch (Yes/No) | Yes | Yes |
Standard Specifications:
300 ton Capacity
6" Stroke
6" Adjustment
24" Shut Height (On Bolster)
72" LR x 36" FB Bed Area
72" LR x 36" FB Slide Area
40-80 VSPM
Equipment and Features:
Air Clutch and Brake
Air Counterbalances
Recirculating Lube System
Hydraulic Tie Rod Nuts
8 Point Gibbing
T-Slotted Ram and Bolster
7" Thick Bolster Plate
21" Wide Windows
49" Floor to top of Bolster
Motors and Controls
Floor Standing
16' 10" Floor to Top of Motor
