| Dimensions | 60" x 73" | 60" x 73" |
| Weight | 5,300# | 5,300# |
Specifications:
Diameter Of Gear: 20" Max.
Speed Of Drive Spdl: 1200 RPM
Motor Required: 5 HP
Offset Of Gear Spdl. Above Or Below Center Of Pinion Spdl.: 3-1/2" Max.
Dis. From Center Of Gear Spdl. To Nose Of Pinion Spdl.: 12" Max, 6" min.
Dis. From Center Of Pinion Spdl. To Nose Of Gear Spdl: 7-3/4" Max.,4-1/8"min
Floor Space: 60" x 73"
Net Weight: 5,300 lbs
FOB TRUCK, WARREN MICHIGAN
Manual/Auto Cycle
Rapid Pinion Advance
Backlash Eliminator
Jogger Valve (Slide)
Load Meter
Hydraulic Chucking
Work Light
Bijur Lube
