| Maximum Workpiece Diameter | 20" | 508 mm |
| Maximum Pinion Outside Diameter | 10" | 254 mm |
| Dimensions | 105" x 81" x 78" | 105" x 81" x 78" |
| Weight | 15,200# | 15,200# |
Specifications:
Capacity:
Gear Outside Diameter, Maximum: 20"
Pinion Outside Diameter, Maximum: 10"
Pinion Spindles (Standard):
Diameter of Taper Hole At Large End: 3-29/32"
Taper Per Foot: 39/64"
Depth of Taper: 2-1/2"
Gear Spindles (Standard):
Diameter of Taper Hole at Large End: 2-19/64"
Taper Per Foot: 1/2"
Depth of Taper: 3"
Pinion Spindle Speed Range, Standard: 0 - 2400 RPM
Electrical Equipment:
Main Motor: 5.5 kW
Hydraulic Motor: 4 kW
Compound Motor: .55 kW
Miscellaneous:
Floor Space: 105" x 81" x 78"
Net Weight: 15,200 lbs
PRICE, RECONDITIONED: $79,500.00
PRICE, CYLED & TESTED: 69,500.00
PRICE, AS TAKEN FROM SERVICE: 62,500.00
Adjustable Hydraulic Brake
Variable Speed Drive Motor
Automatic Lapping Guard
Automatic Meshing
Automatic Preset Backlash
Manual Lapping Compound Replenish System
Remanufactured by Gleason in 1989
