Turbovac Heavy-Duty Double Chamber Vacuum Packaging Machine with Aluminum Cover and Flat Working Surface with 23″ Seal Length
Overview
Description
Description
Our new range of double chambers is reliable, and durable and offers flexibility in volume production. Our machines can be equipped with semi-automatic or automatic cover movement for an even more efficient production. The double chambers can also be equipped with an external pump.
Technical
Seal Length: 23.62” (600 mm) x 4
Vacuum Pump: 63 m³
10 Programmable Control: Yes
Power: 4400 W
Electrical: 190-240V / 60Hz / 3Ph
Maximum Product Height: 7” (180 mm)
Useful Chamber Size (WDH): 24” x 20” x 7” (610 x 508 x 178 mm)
Net Weight: 528 lb. (240 kg.)
Net Dimensions (WDH): 52.95” x 28.34” x 40.98” (1345 x 720 x 1040 mm)
Gross Weight: 677 lb. (307 kg.)
Gross Dimensions (WDH): 59.5” x 32” x 50” (1510 x 820 x 1280 mm)
Optional Parts & Accessories
FILTER PLATES
ITEM: 41483
25mm (6pcs.)
SENSOR
ITEM: 41513
Spec Sheet
Instruction Manual
Parts Breakdown
