| X Axis Travel | 64" | 1,625.6 mm |
| Y Axis Travel | 50" | 1,270 mm |
| Z Axis Travel | 40" | 1,016 mm |
| Feed | 600 IPM | 600 IPM |
| Spindle Motor | 60 hp | 44.7 kW |
| Spindle Speed | 7,500 RPM | 7,500 RPM |
| ATC Capacity | 50 | 50 |
| Spindle Taper | CT-50 | CT-50 |
| Table Size | 64" x 36" | 64" x 36" |
| Max Load | 10,000 lb | 4,535.9 kg |
| Cut Hours | 3,248 hr. | 3,248 hr. |
| Dimensions | 192" x 166" x 136" | 192" x 166" x 136" |
| Weight | 29,700 Lbs. | 29,700 Lbs. |
HAAS CNC Control
Wireless Intuitive Probing (WIPS), eye and software only
1,000 PSI Through Spindle Coolant
Chip Conveyor
Auxiliary Coolant Filter
Auto Door
High Volt Transformer
8 Spare M Functions
5° Indexer
