Overview
Type:
Woodworking Sanders
Manufacturer:
HEESEMANN
Model:
LSM 8/3-OSR
Year:
2005
Stock #:
010939
Description

HEESEMANN LSM-8/3-OSR Wide Belt Finishing Sander
52" and (3) Heads; Equipped with: (1) longitudinal segmented platen head. and (2) Orbital Platens
Machine equipped with HEESEMANN's patented "CSD" selective pressure adjustment system, sensors placed every 16 mm (5/8") The computer control will hold a maximum of (20) programs.
1st Head: Longitudinal segmented platen head.
Segmented Polishing Platen, 20 & 27 HP dual speed motor.
Electronically controlled segments to conform to panel size
2620 x 1350 mm (91.4 x 53.2") Sanding belt.
2nd & 3rd Heads: OSR Dual orbital action head with
(1) high-speed orbit on sanding pad, powered by 3 kW (4.5 HP) motor.
Secondary oscillation movement of platens powered by 1.5 HP motor. Upstream and downstream vacuum chutes on each head for dust localized dust pickup.
Platens feature "quick change" abrasive material; Both orbital heads with variable speed inverter drives.
Out feed Rotary Brush with cleaning brush loading with single end adjustment , 6" max. dia., 3.4 HP motor.
Variable feed speed from 13 to 82 FPM, 6.5 HP feed drive.
In feed and out feed Scissor Lift and Control box shown are not included.
Motorized thickness opening 1/4" to 3-5/32" max. -
Power Consumption: 63 KW, 75 Amps.
Separate display console for CSD control.
