NEW 2025 ROLL-IN SAW DT1340

“The Deep Throat Journeyman” is designed for large jobs that require large levels of complexity and accuracy. This saw has the strength of our other Journeyman saws to make straight or detailed cuts with additional throat clearance.
The wide table and 40" throat allows you to control wide pieces of material as you cut.

DT1340 - Deep Throat Journeyman

SPECIFICATIONS:
FEED SYSTEM.......... N/A
BLADE TRAVEL.......... N/A
CUTTING CAPACITY AT 90 DEG.......... ROUND: 13" RECTANGLE: 40" x 13"
MITER CUT ANGLE RANGE.......... 0 - 45 DEGREES **
BEVEL CUT ANGLE RANGE.......... N/A
CLEARANCE.......... 13" TABLE TO GUIDE
THROAT.......... 40"
BLADE SIZE (SHIPS WITH SAW).......... 3/8" WIDTH x 15' 3" LENGTH 10/14 VARIABLE TOOTH .035 THICK (BI-METAL)
BLADE SIZE (ACCEPTED WIDTHS).......... 1/4”, 3/8”, 1/2”, 5/8” AND 3/4” (“ADJUSTO-BLOK®” GUIDE ROLLER WORKS FOR EACH BLADE WIDTH)
BLADE SPEEDS.......... 70 - 500 SFPM (DIGITAL SPEED CONTROL)
TABLE.......... PRECISION GROUND STEEL TABLE: 24" X 50 1/4"
TABLE HEIGHT.......... 39" FROM FLOOR (NO CASTERS)
MOTOR.......... 2 HP, 220/440V THREE-PHASE
SAW DIMENSIONS.......... 76" W X 80" H X 30" L
SHIPPING DIMENSIONS.......... 47" W X 86" H X 96" L
SHIPPING WEIGHT.......... 1,050 LBS. F.O.B CLEVELAND, OHIO

Extend the life of the saw blade by utilizing the chip blower; adjusting the blade speed with the digital keypad; or by using the optional saw blade welder, grinder, & shear
Product Features
- Double the throat distance of our other Journeyman models
​- Adjusto-Blok® guides for ¼” to ¾” blade widths
​- Extends the life of saw blades with an optional saw blade welder, grinder, & shear
- Accurately control blade speed with the on-board digital inverter drive
