Hitachi Seiki VS40 Vertical Machining Center with 2-Station Pallet Shuttle, Seicos Control, 40 Taper, 12,000 RPM Spindle.
| X | 23.9" | 607.06 mm |
| Y | 16" | 406.4 mm |
| Z | 20" | 508 mm |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 20 | 20 |
| Taper | 40 | 40 |
| Table-W | 35 mm | 1.378" |
| Table-L | 17 mm | 0.6693" |
| # Axis | 3 | 3 |
| Control | CNC | CNC |
| Weight | 17,000 LBS | 17,000 LBS |
Table Size......................35" x 17"
Table Capacity..................770 LBS
Spindle to Table................5.11" - 22.8"
X-Axis Travel...................23.9"
Y-Axis Travel...................16"
Z-Axis Travel...................20"
Spindle Motor...................N/A
Spindle Taper...................CAT-40
Spindle Speed...................12,000 RPM
Number of Tools.................20 ATC
Machine Weight..................17,000 LBS
Seicos E-18M CNC Controller
2-Station Pallet Changer
12,000 RPM, CAT-40 Spindle
Chip Conveyor
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
