USED ESAB AVG2 VIS55

ESAB Avenger 2

Please Note these are spec. when the machine was New and all spec. should be confirmed and inspected.

Featuring:
- 3 Axis Gantry with Rack-and-Pinion Drives
- 4 Meter Wide Cutting Area (157 inch)
- Heavy-Wall Reinforced Box Beam Design
- Welded, Machined Trucks with long wheel base for added stability
- Machined Mating Surfaces for high stiffness and accuracy
- Digital AC Drive Amplifiers for years of maintenance free
operation
- AC Brushless Motors for smooth, accurate motion
- Precision Planetary Gearboxes for accuracy and long life
- Precision Linear Rail Drive Engagement
- Maximum Machine Speed: 1000 ipm (25400 mm/min)
- Cross Axis Powertrack Hose & Cable Carriers
Note:
The Avenger 2 will maintain a machine positioning accuracy of+/-
0.015" in both the "X" and "Y" axis over a six foot by six foot area. The machine repeatability in this area is+/- 0.005". Each machine's performance is factory verified using a laser interferometer according to ISO 230-2 Test Code for Machine Tools. These tolerances can only be met if the rails are installed and maintained per ESAB specifications.

Includes:
- Heavy-duty, precision machined crane rail system
- Machined top and side surfaces
- Machined rack mounting groove for precise rack alignment
- Precision drive rack mounted directly to machined surface
- Fully adjustable mounting pads for adjusting height,
level, straightness
- Hose and cable input system for basic gantry
Advanced Electronic Gas Control System
- Central oxy-fuel gas control system and manifolds.
- Uses electronic proportional flow control valves for Cutting Oxygen, Preheat Fuel Gas, and Preheat Oxygen pressures.
- Allows setting and adjusting gas pressures from the CNC.
- Includes settings for High and Low Preheat pressures.
- Pressures are adjusted on-screen at the Vision CNC.
- Allows gas pressures to be set automatically by the SOP files.
- Pierce Rate is precisely controlled by the CNC.
- Makes oxy-fuel process setup quick, easy, and repeatable.
Oxyfuel T arch Station with Motorized Lifter
Includes:
- Heavy-Duty Motorized Lift with 7" Travel
- Linear Rail for Accuracy and Rigidity
- Ball Screw Lifting Gear for Long Life
- Individual Torch Station Preheat Solenoid Valves
- Automatic T arch Igniter
- Automatic Cutting Oxygen Solenoid Valve
- Brass Torch Holders For Complete Torch Adjustment
- Oxyweld C-67 Torch Package with Three (3) Cutting Tips
- Lifetime Warranty on C-67 T arch
- Excellent Multi-Torch Balancing
- Cutting Capacity up to 20"
- Cost Saving Low Oxygen Consumption
- Easy to read cutting tips.
- Two piece tips sold as pairs or individually
- Nozzle Nut Threads are Internal To Torch for Protection
- Rugged Torch Body with Heavy Wall Oxygen & Mixer Tubes

Expert Motion Plasma VBA System
Automatic Plasma Bevel System with programmable tilt and
rotation, plus automatic height control. Includes ESAB's exclusive Expert Motion integrated electronic control system with a new
compact, light-weight design.

Simple, reliable protractor design
- Precision tactile sensor for accurate height control while
beveling
- Arc voltage height control for straight cutting
- Exclusive Arc Voltage Sample & Hold feature for bevel cutting intricate patterns
- Breakaway torch protection and non-contact initial
height sensing reduce maintenance and alignment
requirements
- Digital AC amplifier and brushless motor for rotation control
- Split-gear zero backlash feedback system for accurate
rotation control
- Up to 400 Amp Oxygen plasma allows bevel cutting of
Carbon Steel up to 1-1/4" thick to 45 degrees
- +/- 45 degree tilt
- +/- 540 degree rotation
- Heavy Duty Motorized Vertical Lifter with Linear Rails
- For use with up to 400 Amp Plasma Systems
Note:
An appropriate post processor is required to support multi-pass beveling.

ESAB m3 600 Amp Precision Plasma System With PT--36 Torch
- Provides "Precision" cutting from 50 to 260 Amps
- Provides "Production" cutting from 50 to 600 Amps
- Allows Plasma Marking And Cutting With The Same Torch
- Pierce up to 1.5" thick Carbon Steel at 400 Amps Oxygen Plasma
- Cuts up to 2.5" thick Carbon Steel at 400 Amps Oxygen Plasma
- Cuts up to 2" thick Stainless Steel or Aluminum with 600 Amp
Nitrogen Plasma
- Cuts up to 6" thick Stainless Steel or Aluminum with 600 Amp
Argon-Hydrogen (H-35) Plasma
