Johnford’s LH Series CNC bridge mills deliver expanded large-part machining capability with an extended Y-axis travel of 2800 mm (110.2″), with optional 3099 mm (122″) configurations to handle parts over 10 feet wide. This extended Y-axis range significantly increases versatility, enabling manufacturers to take on larger, more complex jobs that boost shop throughput and deliver a faster return on investment. Improved efficiency, productivity, and accuracy make the LH Series a smart choice for high-value work.
| X | 122" | 3,098.8 mm |
| Y | 110.2" | 2,799.1 mm |
| Z | 42" | 1,066.8 mm |
| # Axis | 3 | 3 |
| Power | 56 hp | 41.8 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 40 | 40 |
| Table-W | 94.5" | 2,400.3 mm |
| Table-L | 126" | 3,200.4 mm |
| Taper | CAT-50 / BT-50 (HSK-100A opt.) | CAT-50 / BT-50 (HSK-100A opt.) |
| Control | CNC (Oi-MF Plus (31i-MB Plus opt.)) | CNC (Oi-MF Plus (31i-MB Plus opt.)) |
