NEW EMAG VSC400/ VSC400 DUO

The DUO multi-spindle machine offers a cost effective solution for machining in two operations. Featuring two separate machining areas allows the two overhead slides to be programmed independently. Each machining area has an EMAG disc-type turret mounted in the end wall, which can also be programmed independently.

All DUO multi-spindle machines have a MINERALIT® polymer concrete machine base, the damping properties of which are 8 times those of cast iron. Simple, flexible workpiece handling on all VSC series machines, including the multi-spindle machines, includes loading and unloading from either the right or the left.

Precision Coupling Production – High quantities of the highest quality
The cornerstone of the VSC turning machines is a robust machine base of MINERALIT® polymer concrete. The DUO features two separate machining areas, each equipped with an independently programmable overhead slide. Each machining area also features a programmable EMAG disc-type turret, fixed to the front wall. This allows for the two spindles to be allocated to identical or different machining cycles, as required.

A flexible workpiece flow reduces footprint and costs The pick-up spindle allows the turning machines of the VSC series to load themselves. Whether the workpiece is loaded or unloaded from the left or the right, the direction of the workpiece flow – and thus the position of the turning machines in the production line – is customizable. Advantages: smaller footprint and considerably lower link-up costs. Integration into manufacturing systems is guaranteed by the availability of a variety of automation components.

- Workpiece dia., max.: 340 mm | 13.5 in
- Workpiece length, max.: 160 mm | 6.5 in
- Chuck dia., max.: 200 / 400 mm | 8 / 15.5 in
