1996 HAAS VF-8 Vertical Machining Center: Excellent for complex tasks with 64"x40"x30" travel, 20 HP, and 10,000 RPM. Equipped with BT 40 taper, 20 position ATC, and 3-axis operation. Table size 64"x36". Ideal for precision manufacturing.
| X | 64" | 1,625.6 mm |
| Y | 40" | 1,016 mm |
| Z | 30" | 762 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 7,500 RPM | 7,500 RPM |
| # ATC | 20 | 20 |
| Taper | BT 40 | BT 40 |
| Table-W | 36" | 914.4 mm |
| Table-L | 64" | 1,625.6 mm |
| # Axis | 3 | 3 |
| Control | CNC | CNC |
X-Axis Travel: 64"
Y-Axis Travel: 40"
Z-Axis Travel: 30"
Table Size: 64" x 36"
Max Table Load: 4,000 LBS
Spindle Speed: 7,500 RPM
Spindle Motor: 20 HP
Spindle Taper: BT 40
Auto Tool Changer: 20 Positions
Electrical Requirements: 360-480 V; 3 Ph; 50/60 Hz
Full/Largest Load: 20 Amp
EQUIPPED WITH:
Haas CNC Control
USB Interface Upgrade
4th Axis Wiring
Programmable Coolant Nozzles
Rigid Tapping
Chip Auger
Assorted Unused BT-40 Tools (approx 12 holders)
