Printing Process:
Continuous Fiber Reinforcement (CFR)
Z Layer Resolution:
50 μm – 250 μm
Physical Dimensions:
Width: 584 mm
Depth: 483 mm
Height: 914 mm
Weight: 48 kg / 106 lbs
Build Volume:
Width: 330 mm
Depth: 270 mm
Height: 200 mm
Materials:
Plastics: Onyx, Onyx FR, Onyx ESD, Nylon White, P-PLA, S-TPU
Fibers: Carbon Fiber, Carbon Fiber FR, Fiberglass, Aramid Fiber (Kevlar), HSHT Fiberglass
Tensile Strength: 800 MPa (25.8x ABS, 2.6x 6061-T6 Aluminum)
Tensile Modulus: 60 GPa (26.9x ABS, 0.87x 6061-T6 Aluminum)
Power:
100-240VAC, 150W (2 A Peak)
Laser:
In-process inspection, active print calibration, bed leveling
