USED 1999 Mazak Integrex 200SY

X2nd Chuck Description: Hydraulic
X2nd Turret Live Tooling: false
X4th Axis: false
X5th Axis: true
Additional Control Options: Polar Coordinates Input

Additional Machine Specs: Max Tool Length: 9.84”

Max Tool Diameters: 3.54” / 4.72”

Max Tool Weight: 15.4 Lbs

Tooling Type: Kennametal KM63

Bar Capacity: 2.0
B Axis: true
C Axis: true
Chip Removal: None
Chuck Size: 8.5
Chuck Type: Hydraulic
Control Make Model: Mazatrol 640MT CNC Control
Control Options: Coordinate Rotation and Scaling, Synchronized Tapping, EIA/ISO Code Input Function
Distance Between Centers: 40.0
Electrical: 460V
Live Milling Hp: 15
Live Milling Max Rpm: 6,000
Live Milling Thru Spindle Coolant: false
Live Tooling Milling: true
Max Cutting Turning Diameter: 21.25
Max Swing Over Bed: 21.25
Max Turning Cutting Length: 40.0
Programmable Tailstock: false
Second Chuck Size: 7.0
Second Spindle Bore: 1.73
Second Spindle Motor: 10
Second Spindle Speed: 5,000
Single Turret: false
Single Turret Live Tooling: false
Spindle Bore: 2.05
Spindle Motor: 25
Spindle Speed: 5000.0
Sub Spindle: true
Tailstock: false
Tool Positions: 40.0
Twin Turret: false
X Travel: 20.87
Y Axis: true
Z Travel: 41.92
