Increase Efficiency Without Sacrificing Quality!
Cutting Capacity Round 90°: 0.4″-3.15″
Cutting Capacity Square 90°: 0.4″-2.36″
Blade Drive: 15 HP VFD
Blade Speed: 50-200 MPM
Blade Size: Carbide/ Cermet tipped: 285 mm x 1.7 mm kerf
Bar Stock Length: 10′-20′
Trim Cut: Zero or programmable from 0.4′ or longer
Cut off Length: Min 0.24” up to 39”
Single Stroke: 40″
Remnant Length: 3.35” + cut length + cutter thickness
Hydraulic Motor: 3 HP
Bar Loading Magazine: Inclined storage width of 27.9″ for rounds
Machine Capacity: 6,613 lbs.
Machine Weight: 6613 lbs.
Dimensions (w x l x h): 85” x 102” x 88″
