Does the Work of Five Conventional Band Saws!
Cutting Capacity Round 90°: 0.4″-2.55″
Cutting Capacity Square 90°: 0.4″-1.96″
Blade Drive: 10 HP VFD
Blade Speed: 164-656 SFM
Blade Size: Carbide/Cermet tipped: 9.8″ x 0.08″ kerf
Bar Stock Length: 10′-20′
Trim Cut: Zero or programmable from 0.4′ or longer
Cut off Length: Min 0.24” up to 39”
Single Stroke: 20″
Remnant Length: 1.57” + cut length + blade thickness
Hydraulic Motor: 3 HP
Bar Loading Magazine: Inclined storage width of 27.9″ for rounds
Machine Capacity: 4400 lbs.
Machine Weight: 5500 lbs.
Dimensions (w x l x h): 77” x 98” x 75”
