High Cutting Performance on a Wide Variety of Materials
Cutting Capacity Round 90°: 1.96″- 7.87″
Cutting Capacity Square 90°: 1.96″- 6.49″
Blade Drive: 50 HP VFD
Blade Speed: 164-656 SFM
Blade Size: Carbide/Cermet tipped: 25.59″ x 0.14″ kerf
Bar Stock Length: 10′-40′
Trim Cut: Zero or programmable from 0.79′ or longer
Cut off Length: Min 0.79″ up to 236″
Single Stroke: 40′
Remnant Length: 4.72″ + cut length
Hydraulic Motor: 5 HP VFD
Bar Loading Magazine: Inclined storage width of 55″ for rounds
Machine Capacity: – lbs.
Machine Weight: 14,770 lbs.
Dimensions (w x l x h): 86” x 96” x 86”
