Designed for Operator Safety
Cutting Capacity Round 90°: 1.96″- 7″
Cutting Capacity Square 90°: 1.96″-5.11″
Blade Drive: 40 HP VFD
Blade Speed: 164-656 SFM
Blade Size: Carbide/Cermet tipped: 22″ x 0.12″ kerf
Bar Stock Length: 10′-20′
Trim Cut: Zero or programmable from 0.4′ or longer
Cut off Length: Min 0.4″ up to full bar length
Single Stroke: 40″
Remnant Length: 4.72″ + cut length
Hydraulic Motor: 3 HP VFD
Bar Loading Magazine: Inclined storage width of 55″ for rounds
Machine Capacity: 19,800 lbs.
Machine Weight: 12,100 lbs.
Dimensions (w x l x h): 97” x 104” x 70”
