Brand – STEFA Model – VH315 Type – Folding Machines New – In Stock
Max Thickness: 0.0591″
Max Thickness (gauge): 16 gauge
Overall Length: 10.5′
Control: CNC (Alligator)
Model VH315 Max. thickness admissible 1.5 mm steel – 2 mm Alu – .9 mm stainless Working length 3200 mm No. Arms 4 Max. cut capacity (slitter) 3 mm mild steel Backgauge range (max – min) 1110mm <-> 5mm Standard backgauge tolerance -0,1 / +0,2 mm Servomotor backgauge tolerance -0,01 / + 0,02 mm No. backstops 3 Standard backgauge speed ~70mm/s Servomotor backgauge speed 250mm/s Opening height clamping beam 260mm Max. rotation of bending beam 145º Bending tolerance +/- 1º Hydraulic power 3 kW Weight 8,512 lbs Colors RAL2008 / RAL7043 (Light orange, dark grey)
New from Stefa the VH315 (10.5′ x 16g) Hybrid (Hydra-electric) CNC folder with built in slitter Includes on-site up and training
