Innovative Modular Design• Easily integrates with automation modules for a full-system solution.• Custom-configurable from basic setups to high-end operations.
Bending Force: 150 Tons
Bending Length: 126”
Distance Between Columns: 106.2”
Stroke: 11.8”
Daylight: 22.8”
Throat Depth: 17.7”
Table Width: 3.54”
Table Height: 37.4”
Positioning Accuracy: ±0.00019”
Rapid Speed: 519.7 IPM
Work Speed: 35.4 IPM
Return Speed: 472 IPM
X-Axis Travel: 31.5”
R-Axis Travel: 9.8”
Z-Axis Travel: 100.4”
Hydraulic Pressure: 275 Bar
Servo Motor Power: 2 x 5.7 kW
Temperature Range: 0°C to +40°C
Dimensions (LxWxH): 5150 x 2000 x 3050 mm
Weight: 25,960 kg
Power Supply: 220V–480V, 3-phase, 50/60Hz
CNC Control: DELEM DA60 Series (Netherlands)
Electrical: SIEMENS/SCHNEIDER (Germany)
Hybrid Servo: ePrAX® Hybrid System
Laser Safety: LazerSafe PCSS A1 + IRIS Block (Australia)
Linear Guides: HEIDENHAIN / GIVI (Germany)
Servo Motors: DELTA (Taiwan)
Foot Switch: SIEMENS (Germany)
Hydraulics: HOERBIGER (Germany)
Ball Screws & Guides: HIWIN (Taiwan)
Tooling: Manual Clamps, Punch, Die, Riser Block
