Guaranteed quality at your finger tips.
Easy-to-use, productivity and efficency, flexibility.
Advantages
Set up precision and reliability. The operator easily adjusts all movements due to a hand wheel with mechanical decimal readouts located on the front of the machine.
Spindle moulder fence with mechanical programming: maximum set-up speed and ease-of-use. No more test runs due to digital readouts that ensure accuracy to a tenth of a millimetre in positioning the two worktables.
Max. useful spindle length mm / inches 140 / 5.5
Spindle speed (at 50 Hz) rpm 3000/4500/6000/7000/10000
Max. diameter of the profiling tool mm / inches 250 / 9.8
Max. tool diameter retractable
-under the table at 90° mm / inches 320 / 12.6
Max. diameter of the tenoning tool
-with spindle diam. 30-35 (40-50) mm / inches 300 / 11.8
Three-phase motor Hp 10
