USED 2008 MIGHTY VIPER NOT PROVIDED

Equipped With
MIGHTY VIPER 3240AG CNC BRIDGE TYPE CNC MACHINING CENTER
New 2008
SPECIFICATIONS:

Working Surface of Table          125.98" x 80.31"
  Travel:                                 X-Axis                    120.08"
          Y-Axis                    94.49"
          Z-Axis                    42.13"
  Maximum Table Load                24,250 Lbs.
  Dist, Spindle Center to Column    16.22"
  Width Between Column              98.82"
  Dist, Spindle End to Table        15.35" - 57.48"
  Spindle Type                      Gear
  Spindle Speeds                    Up to 6,000 Rpm
  Spindle Nose Taper                Iso #50
  Cutting Feed Rate                 0.34 - 196.8 Ipm
  Rapid Travers Rate X,Y,Z          393 Ipm
  Tool Changer                      40 Tool
  Maximum Tool Weight               44 lbs.
  Maximum Tool Size                 5.11" x 13.78"
  Tool SHank                        Cat #50
  Spindle Drive Motor               30 Hp



  Equipped With:


  Mitsubishi M730 Cnc Control
  Automatic Lubrication System
  40 Tool Tool Changer
  Leveling Bolts & Blocks
  Rs232 Serial Interface
  Coolant System
  Spindle Oil Cooler
  Link Type Chip Conveyor
  Convection Heat Exchanger in Control Cabinet
  Operation Manual & Electrical Drawing
  Remote Manual Pulse Generator
