Equipped With
SBS 1020/2,5
SBS 1270/2,0
Working Area
Working length
40 in
50 in
Plate thickness (max.)
0.1 in
0.08 in
Bending bar angle (range)
135¡
Measures and Weights
Overall dimensions (length x width x height)
54x34x47 in
63x36x47 in
Weight
627 lbs
726 lbs
For formed component bending
Compression spring for top counterbalance
Cam lock and rebound spring for bending beam counterbalance
Bow handle for bending beam rotation
Adjustable bending angle stop with scale up to 135¡
Segmented top beam tools
Segment size: 1", 1.2", 1.375", 1.5", 1.75", 2", 3", 4", 6", 8", 10.5"
