Equipped With
SSB 32 Xn
SSB 40 Xn
Working Area
Drilling capacity
1.26 in
1.57 in
Tapping capacity, steel
M 20
M24
Table set up area
20x17 in
21x17 in
Table stroke
19 in
22 in
Quill stroke
6 in
7 in
Table swivel range (max.)
± 45¡
Spindle nose-to-table distance (max.)
25 in
24 in
Spindle nose-to-foot distance
47 in
Throat
13 in
Column diameter
5 in
6 in
Head travel
11 in
Head swivel range
± 45¡
-
Headstock
Spindle mount
MT 4
Spindle speed
(12) 125 - 3,030 rpm
(12) 75 - 2,020 rpm
Feed
Quill feeds
0.004; 0.008; 0.12 / 0.47 in/R in/R
0.005; 0.01; 0.02/ 0.12 in/R
Drive Capacity
Main motor rating
1.6 Hp
Motor rating
1.5 / 400 Hp/V
Measures and Weights
Overall dimensions (length x width x height)
34x20x78 in
38x25x88 in
Weight
1,188 lbs
1,210 lbs
Heavy cast-iron construction with thick-walled column
Tapping feature
Automatic drill feeds controlled by an electromagnetic clutch
Includes coolant system and work lamp
Table rotates and swivels ±45¡
tapping unit
protective shield
LED work lamp
coolant system
operating tools
operator manual
