Equipped With
Cutting Capacities
Cutting speed
131/262 fpm
Feed per scale division X-axis
19.69 in
Working height
33 in
Cutting capacity 90¡ round
13 in
Cutting capacity 90¡ - square
10 in
Cutting capacity 90¡ - flat
18x10 in
Cutting capacity 30¡ (round)
8 in
Cutting capacity 30¡ (square)
8 in
Cutting capacity 30¡ (flat)
8x10 in
Cutting capacity 45¡ - round
12 in
Cutting capacity 45¡ - square
10 in
Cutting capacity 45¡ - flat
12x10 in
Cutting capacity 60¡ (round)
12 in
Cutting capacity 60¡ (square)
10 in
Cutting capacity 60¡ (flat)
15x10 in
Drive Capacity
Main motor rating
2/3 Hp
Motor rating hydraulic pump
1 Hp
Motor rating coolant pump
0.1 Hp
Measures and Weights
Belt dimensions
155.91x1.06x0.04 in
Overall dimensions (length x width x height)
255x89x56 in
Weight
3,344 lbs
Part No.
152820
Automatic workpiece feed and cutting cycle can be programmed via PLC
Programming is easy via a user-friendly graphic touchscreen interface
Input can be in metric or imperial units
2-step drive motor for easy saw blade speed adjustments
Rigid, adjustable saw blade guides can easily be adjusted for different workpiece diameters
Safety during automatic operation is ensured by secure workspace enclosures
Linear and transverse feed/discharge roller tracks are part of the standard equipment
Intuitive operation and efficient control of all parameters
Reliable touchscreen input panel
In Manual Mode, all machine functions can be selected and adjusted via touchscreen
In Auto Mode, feed distance and number of cuts can be programmed within the respective configuration
All machine parameters can be checked by the operator via user-friendly menus
PLC control
chip removal brush
feed roller table (118 in)
hydraulic workpiece feed
bimetallic band saw blade
touch screen monitor
coolant system
operating tools
operator manual
